PARAMETERS:

◆1.Dimension: 4400×3600×2250MM

◆2.Cloth speed: 0～100M/MIN

◆3.Power supply: 380V

◆4.Motor power: 2.7KW

◆5.Useful width: 2500MM

◆6.Maximum coil diameter: 500MM

◆7.Edge accuracy: ±5MM

◆8.Length accuracy: more than≤0.5%

Features:

◆1.Applicable for the quality inspection Knitted fabric for textile, printing, and dyeing enterprises.

◆2.Infrared ray detects the edge of the automatic tracking, automatic alignment of the edge of the cloth, no cloth automatic shutdown.

◆3.Automatically control the front and back tension frame, protect the fabric from the influence of tension when rolling.

◆4.Front and back selvedge device, prevent crease and rolling with edge blowing device.

◆5.；Frequency conversion speed control, easy to operate, and can be equipped with another electronic scale.

◆6.Cutting knife/automatic cutting knife available, Stainless steel split/integrated table available.

◆7.Fabric roller is equipped with speed differential mechanism, adjust the softness and hardness of fabric roll easily.
