PARAMETERS:

◆1.Dimension: 2800×3300×6600MM

◆2.Cloth speed: 0～100M/MIN

◆3.Power supply: 380V

◆4.Motor power: 9.8KW

◆5.Useful width: 1500～2700MM

◆6.Material: Q235 Steel 4MM (solid thickness 3.75)

Features:

◆1.Suitable for circular knitted fabrics or rope-like woven fabrics and knitted fabrics after dyeing to cut the fabric to be twisted and open the width of the press water use.

◆2.Automatic thread cutting function, which makes the cylinder fabric cutting, automatic untwisting, automatic centering, after spreading the flat width of the cloth.

◆3.Adopting frequency conversion speed control, simple and convenient operation.

◆4.Automatic de-twisting with centering device for ultra-thin and silky fabrics.

◆5.The machine has a small footprint, moderate height and stable machine performance.

◆6.Adopting Hangzhou Qinshang automatic cloth cutting head.

◆7.This machine ropes into the cloth and swings into the cloth.
