PARAMETERS:

◆1.Dimension: 2780×3100×1890MM

◆2.Cloth speed: 0～100M/MIN

◆3.Power supply: 380V

◆4.Motor power: 3KW

◆5.Useful width: 2300～3000MM

◆6.Maximum coil diameter: 500MM

◆7.Edge accuracy: ±5MM

◆8.Length accuracy: more than≤0.5%

Features:

◆1. Applicable for knitted fabric quality inspection in textile, printing and dyeing enterprises.

◆2. Built-in infrared edge sensor realizes automatic selvedge tracking and alignment; the machine will stop automatically when no fabric is detected.

◆3. Front & rear tension frames are automatically controlled to protect fabrics from tension damage during winding.

◆4. Equipped with front and rear selvedge blowing devices to avoid wrinkles and uneven rolling.

◆5. Adopts variable frequency speed regulation for simple operation; an electronic scale can be installed as an option.

◆6. Optional accessories: manual cutting knife / automatic cutting knife; stainless steel split table / integrated table.

◆7. The fabric winding roller is fitted with a speed differential mechanism for easy adjustment of fabric roll tightness.
