PARAMETERS:

◆1.Dimension: 2780×3300×2000MM

◆2.Cloth speed: 0～100M/MIN

◆3.Power supply: 380V

◆4.Motor power: 2.7KW

◆5.Useful width: 2300～3000MM

◆6.Maximum coil diameter: 500MM

◆7.Edge accuracy: ±5MM

◆8.Length accuracy: more than≤0.5%

Features:

◆1. Applicable for textile and garment enterprises to test the quality of various fabrics such as chemical fiber and cotton.

◆2. Equipped with infrared edge detection and automatic edge tracking & alignment; the machine will shut down automatically when there is no fabric.

◆3. Front and rear fabric spreading rollers prevent creases and rolling, fitted with an edge blowing device.

◆4. Rolling speed is controlled by a variable frequency converter.

◆5. Dispersed feeding frame; automatic fabric unwinding is available as an option.

◆6. A bulk fabric feeding frame or amplitude expander can be installed, with automatic fabric unwinding optional.
