PARAMETERS:

◆1.Dimension:2700×3200×3000MM

◆2.Cloth speed: 0～100M/MIN

◆3.Power supply: 380V

◆4.Motor power: 2KW

◆5.Useful width: 2200MM

◆6.Edge accuracy: ±5MM

Features:

◆1. Suitable for fabric splicing and widely applied in the textile industry.

◆2. The frequency can be easily controlled and adjusted via an inverter.

◆3. It swings fabrics onto trolleys to facilitate subsequent working procedures.

◆4. Fitted with a high-precision fabric length counter.

◆5. The infrared sensor automatically stops the machine when fabric runs out.

◆6. It supports dropping of plush fabrics and normal woven fabrics.
