PARAMETERS:

◆1.Dimension:4050×2924×2420MM

◆2.Cloth speed: 0～35M/MIN

◆3.Power supply: 380V

◆4.Motor power: 6.75KW

◆5.Useful width: 2500MM

◆6.Stitch: 5～15MM

◆7.Air Pressure Requirements: 6-8KG/CM3

Features:

◆1. This machine is specially developed for edge sewing and stitching of folded knitted fabrics before dyeing, and it works perfectly for pre-dyed elastic coated fabrics such as LYCRA and faux shearling.

◆2. The infrared photo-eye sensor realizes automatic tracking and hydraulic selvedge folding.

◆3. It features automatic fabric centering correction, equipped with spreading rollers to smooth out fabric wrinkles.

◆4. Adopts imported sewing heads manufactured by Japan KANSAI.

◆5. Equipped with variable frequency drive and PLC synchronous control system for steady running performance.

◆6. Single-row slat type fabric guide ensures stable fabric conveying.
