PARAMETERS:

◆1.Dimension: 3650×3300×2300MM

◆2.Cloth speed: 0～100M/MIN

◆3.Power supply: 380V

◆4.Motor power: 2.2KW

◆5.Useful width: 2300MM 2500MM

◆6.Maximum coil diameter: 400MM

◆7.Edge accuracy: ±5MM

◆8.Length accuracy: more than≤0.5%

Features:

◆1. Applicable to textile and garment enterprises for quality inspection of various fabrics including cotton and chemical fiber.

◆2. Adopts infrared edge detection for automatic edge tracking and alignment; the machine stops automatically when no fabric is detected.

◆3. Front and rear spreading rollers prevent creases and curling, equipped with an edge blowing device.

◆4. Winding speed is regulated by a variable frequency converter.

◆5. Dispersed feeding frame; automatic fabric unwinding is available as an option.

◆6. A bulk fabric feeding rack or fabric expander can be fitted, with optional automatic fabric unwinding.

◆7. Both upper and lower light boxes are equipped with LED lamps.
