PARAMETERS:

◆1.Dimension: 4000×2070×2450MM

◆2.Cloth speed: 0～100M/MIN

◆3.Power supply: 380V

◆4.Motor power: 8.5KW

◆5.Useful width: 1450MM

◆6.Maximum coil diameter: 500MM

◆7.Edge accuracy: ±5MM

◆8.Length accuracy: more than≤0.5%

Features:

◆1. Suitable for textile and garment enterprises to conduct quality inspection on cotton, chemical fiber and other fabrics.

◆2. It adopts infrared edge detection to realize automatic edge tracking and alignment; the machine will shut down automatically when no fabric is fed.

◆3. Front and rear fabric spreading rollers prevent creases and curling, and the machine is fitted with an edge blowing device.

◆4. The winding speed is controlled by a variable frequency converter.

◆5. Equipped with a dispersed feeding frame; automatic fabric unwinding is available as an option.

◆6. A bulk fabric feeding rack or fabric expander can be installed, with optional automatic fabric unwinding function.

◆7. The equipment is fully enclosed with a yellow housing, including the detector probe.
