PARAMETERS:

◆1.Dimension: 2900×3100×1690MM

◆2.Cloth speed: 50～120M/MIN

◆3.Power supply: 380V

◆4.Motor power: 3KW

◆5.Useful width: 2300～3000MM

◆6.Maximum coil diameter: 500MM

◆7.Edge accuracy: ±5MM

◆8.Length accuracy: more than≤0.5%

Features:

◆1. Applicable to textile and garment enterprises for quality inspection of cotton, chemical fiber and other various fabrics.

◆2. Equipped with infrared edge detection to realize automatic edge tracking and alignment; the machine automatically stops when no fabric is detected.

◆3. Front and rear spreading rollers eliminate creases and fabric curling, and the unit is fitted with an edge blowing device.

◆4. Winding speed is adjustable via a variable frequency converter.

◆5. Standard dispersed feeding frame; automatic fabric unwinding is optional.

◆6. A bulk fabric feeding rack or fabric expander can be fitted, with optional automatic fabric unwinding.

◆7. Supplied with trolley-type yarn rollers; an electronic scale is available as an optional accessory.
