PARAMETERS:

◆1.Dimension: 2900×2400×1650MM

◆2.Speed: 600/RPM

◆3.Power supply: 380V

◆4.Motor power: 18.5KW

◆5.Weight: 4000～4200Kg

◆6.Diameter of basket: 2000MM

◆7.Height of basket: 800MM

◆8.Content of basket: 2400ltr.

◆9.Dry material capacity: 400Kg.

◆10.Wet material capacity: 1200Kg

◆11.Material: 304 Stainless steel(Inner thickness 4MM Outer thickness 3MM)

Features:

◆1. Suitable for textile printing and dyeing industries, used for dewatering woven fabrics, knitted fabrics, garments and stranded yarns.

◆2. A pneumatic protection device is fitted on the lid switch to guarantee safe operation and extend service life.

◆3. High-quality stainless steel inner and outer baskets; large capacity, high dewatering efficiency, low energy consumption, smooth and quiet operation.

◆4. Adopts inverter control system to replace mechanical brakes and cut maintenance costs.

◆5. Features automatic timing, automatic braking and adjustable rotating speed.

◆6. Stainless steel cloth feeding and discharging racks are available as options for easier operation.
